This unit does everything the FG-100 did, now with a new AUTO HOLD feature that ends measurements automatically once the tip temperature is stabilized. This feature can minimize individual differences in measuring temperatures. The FG-100B can also display in both °C and °F!
Note:For thermometer with the Calibration Certificate, please order .
Specifications
| Part No. | FG100B-03 | |
| Resolution | °F | °C |
| Range of Measurement1 | 32 - 1300°F | 0 - 700°C |
| Applied Sensor | K(CA) Type Thermocouple | |
| Measurement Tolerance2 | ±6°F (572 - 1112°F) | ±3°C (300 - 600°C) |
| Power Supply | 9V battery (alkaline cell recommended) | |
| Dimensions (excluding protrusions) | 75 x 44 x 140 mm 2.95 x 1.73 x 5.51 in. | |
| Weight (w/out battery) | 0.28 lbs. (125 g) | |
| Operating Environment | 0-40°C (32-104°F) 20-90% RH no condensation | |
| Pollution Degree Rating | Pollution Degree 2 | |
| Standards & Ratings | ||
1Temperature sensor (PN: 191-212) can only be used to measure temperatures below 500 °C (932°F). To measure higher temperatures, use an applicable temperature probe.
2Measurement tolerance is ±5°C / ±10°F for measurements outside the range given for measurement tolerance above.
What's in the box?
| Description | Part No. |
| FG-100 Tip Thermometer | FG100B-03 |
| User Manual | --- |
| Replacement Sensor (pack of 10) | |
| 9V Battery (sample only) | --- |
To preserve battery life, the auto shutoff feature turns the thermometer off when not used for three minutes. The thermometer design allows for easy measurements from right or left handed operators.
• The sensor (P/N: 191-212) has a special metal alloy coating that resists corrosion and oxidation. Note: the 191-212 sensor can measure temperatures up to 500°C (932°F). For higher temperatures, please use the applicable temperature probe (see Accessories: P/N A1310.)
• Sensor replacement is quick and easy
• AUTO HOLD feature
• User selectable easy-to-read temperature display allows the reading to display in either °C or °F
• Optional temperature probe to measure solder pot temperatures
